Integrated HMI computer
Combines the touchscreen display and embedded computer in one industrial unit using Intel Celeron J1900.
✨ New Arrivals Just Dropped!Explore
17" all-in-one Panel PC, 1280x1024, Intel Celeron J1900
I-Series 2nd Gen / Panel PC
17" I-Series 2nd Gen panel PC with Intel Celeron J1900 and 1280 x 1024 resolution
This I-Series 2nd Gen all-in-one panel PC powered by Intel Celeron J1900 with a 17-inch 1280 x 1024 touchscreen is built for machine control, data collection, and operator-interface work. Its IP65 front-panel protection helps protect the system in demanding production settings.
- Touch: Capacitive, Resistive
- Brightness: Standard, Sunlight-Readable, Auto Brightness Sensor + Sunlight-Readable
- OS: Ubuntu, Windows 10 Pro, Windows 10 LTSB, Windows 11 Pro
- Dimensional drawing available
- 3D STEP available
Display
17" screen with 1280 x 1024 resolution
Configuration
Touch: Capacitive, Resistive; Brightness: Standard, Sunlight-Readable, Auto Brightness Sensor + Sunlight-Readable; OS: Ubuntu, Windows 10 Pro, Windows 10 LTSB, Windows 11 Pro
Engineering files
Dimensional drawing available; 3D STEP available
Key specifications
- Screen size
- 17"
- Resolution
- 1280 x 1024
- Aspect ratio
- 5:4
- Processor
- Intel Celeron J1900
- Touch input
- Configurable capacitive or resistive touch
- Brightness options
- Standard, Sunlight-Readable, Auto Brightness Sensor + Sunlight-Readable
- Environmental protection
- IP65 front-panel protection
- Touch options
- Capacitive, Resistive
- Operating system options
- Ubuntu, Windows 10 Pro, Windows 10 LTSB, Windows 11 Pro
- Product family
- I-Series 2nd Gen
- Product type
- Panel PC
- SKU
- IMD170-W210-J1900-SD-NONE
- Specification PDF
- available (603 KB)
- 3D CAD model
- STEP file available (10.8 MB)
Recommended uses
- Machine HMI and SCADA terminals
- Packaging, production, and inspection stations
- Kiosks, self-service terminals, and control cabinets
- Line-side dashboards and industrial data collection
Select Touchscreen
Select Screen Brightness
Select Operating System
From $47,340.00
Original: $157,800.00
-70%17" all-in-one Panel PC, 1280x1024, Intel Celeron J1900—
$157,800.00
$47,340.00
Description
I-Series 2nd Gen / Panel PC
17" I-Series 2nd Gen panel PC with Intel Celeron J1900 and 1280 x 1024 resolution
This I-Series 2nd Gen all-in-one panel PC powered by Intel Celeron J1900 with a 17-inch 1280 x 1024 touchscreen is built for machine control, data collection, and operator-interface work. Its IP65 front-panel protection helps protect the system in demanding production settings.
- Touch: Capacitive, Resistive
- Brightness: Standard, Sunlight-Readable, Auto Brightness Sensor + Sunlight-Readable
- OS: Ubuntu, Windows 10 Pro, Windows 10 LTSB, Windows 11 Pro
- Dimensional drawing available
- 3D STEP available
Integrated HMI computer
Combines the touchscreen display and embedded computer in one industrial unit using Intel Celeron J1900.
Display
17" screen with 1280 x 1024 resolution
Configuration
Touch: Capacitive, Resistive; Brightness: Standard, Sunlight-Readable, Auto Brightness Sensor + Sunlight-Readable; OS: Ubuntu, Windows 10 Pro, Windows 10 LTSB, Windows 11 Pro
Engineering files
Dimensional drawing available; 3D STEP available
Key specifications
- Screen size
- 17"
- Resolution
- 1280 x 1024
- Aspect ratio
- 5:4
- Processor
- Intel Celeron J1900
- Touch input
- Configurable capacitive or resistive touch
- Brightness options
- Standard, Sunlight-Readable, Auto Brightness Sensor + Sunlight-Readable
- Environmental protection
- IP65 front-panel protection
- Touch options
- Capacitive, Resistive
- Operating system options
- Ubuntu, Windows 10 Pro, Windows 10 LTSB, Windows 11 Pro
- Product family
- I-Series 2nd Gen
- Product type
- Panel PC
- SKU
- IMD170-W210-J1900-SD-NONE
- Specification PDF
- available (603 KB)
- 3D CAD model
- STEP file available (10.8 MB)
Recommended uses
- Machine HMI and SCADA terminals
- Packaging, production, and inspection stations
- Kiosks, self-service terminals, and control cabinets
- Line-side dashboards and industrial data collection
