Integrated HMI computer
Combines the touchscreen display and embedded computer in one industrial unit using Intel Core i3.
✨ New Arrivals Just Dropped!Explore
15" all-in-one Panel PC, 1024x768, Intel Core i3
I-Series 2nd Gen / Panel PC
15" I-Series 2nd Gen panel PC with Intel Core i3 and 1024 x 768 resolution
This I-Series 2nd Gen all-in-one panel PC powered by Intel Core i3 with a 15-inch 1024 x 768 touchscreen is built for machine control, data collection, and operator-interface work. Its IP65 front-panel protection helps protect the system in demanding production settings.
- Touch: Capacitive, Resistive
- Brightness: Standard, Sunlight-Readable, Auto Brightness Sensor + Sunlight-Readable
- OS: Ubuntu, Windows 10 Pro, Windows 10 LTSB, Windows 11 Pro
- Dimensional drawing available
- 3D STEP available
Display
15" screen with 1024 x 768 resolution
Configuration
Touch: Capacitive, Resistive; Brightness: Standard, Sunlight-Readable, Auto Brightness Sensor + Sunlight-Readable; OS: Ubuntu, Windows 10 Pro, Windows 10 LTSB, Windows 11 Pro
Engineering files
Dimensional drawing available; 3D STEP available
Key specifications
- Screen size
- 15"
- Resolution
- 1024 x 768
- Aspect ratio
- 4:3
- Processor
- Intel Core i3
- Touch input
- Configurable capacitive or resistive touch
- Brightness options
- Standard, Sunlight-Readable, Auto Brightness Sensor + Sunlight-Readable
- Environmental protection
- IP65 front-panel protection
- Touch options
- Capacitive, Resistive
- Operating system options
- Ubuntu, Windows 10 Pro, Windows 10 LTSB, Windows 11 Pro
- Product family
- I-Series 2nd Gen
- Product type
- Panel PC
- SKU
- IMD150-W210-i3-SD-NONE
- Specification PDF
- available (3.7 MB)
- 3D CAD model
- STEP file available (11.1 MB)
Recommended uses
- Machine HMI and SCADA terminals
- Packaging, production, and inspection stations
- Kiosks, self-service terminals, and control cabinets
- Line-side dashboards and industrial data collection
Select Touchscreen
Select Screen Brightness
Select Operating System
From $66,480.00
Original: $221,600.00
-70%15" all-in-one Panel PC, 1024x768, Intel Core i3—
$221,600.00
$66,480.00
Description
I-Series 2nd Gen / Panel PC
15" I-Series 2nd Gen panel PC with Intel Core i3 and 1024 x 768 resolution
This I-Series 2nd Gen all-in-one panel PC powered by Intel Core i3 with a 15-inch 1024 x 768 touchscreen is built for machine control, data collection, and operator-interface work. Its IP65 front-panel protection helps protect the system in demanding production settings.
- Touch: Capacitive, Resistive
- Brightness: Standard, Sunlight-Readable, Auto Brightness Sensor + Sunlight-Readable
- OS: Ubuntu, Windows 10 Pro, Windows 10 LTSB, Windows 11 Pro
- Dimensional drawing available
- 3D STEP available
Integrated HMI computer
Combines the touchscreen display and embedded computer in one industrial unit using Intel Core i3.
Display
15" screen with 1024 x 768 resolution
Configuration
Touch: Capacitive, Resistive; Brightness: Standard, Sunlight-Readable, Auto Brightness Sensor + Sunlight-Readable; OS: Ubuntu, Windows 10 Pro, Windows 10 LTSB, Windows 11 Pro
Engineering files
Dimensional drawing available; 3D STEP available
Key specifications
- Screen size
- 15"
- Resolution
- 1024 x 768
- Aspect ratio
- 4:3
- Processor
- Intel Core i3
- Touch input
- Configurable capacitive or resistive touch
- Brightness options
- Standard, Sunlight-Readable, Auto Brightness Sensor + Sunlight-Readable
- Environmental protection
- IP65 front-panel protection
- Touch options
- Capacitive, Resistive
- Operating system options
- Ubuntu, Windows 10 Pro, Windows 10 LTSB, Windows 11 Pro
- Product family
- I-Series 2nd Gen
- Product type
- Panel PC
- SKU
- IMD150-W210-i3-SD-NONE
- Specification PDF
- available (3.7 MB)
- 3D CAD model
- STEP file available (11.1 MB)
Recommended uses
- Machine HMI and SCADA terminals
- Packaging, production, and inspection stations
- Kiosks, self-service terminals, and control cabinets
- Line-side dashboards and industrial data collection
